DS-600F Foot type impulse sealer
DS-600F Foot type impulse sealer
DS-600F Foot type impulse sealer
DS-600F Foot type impulse sealer
DS-600F
60cm Foot type impulse sealer

•Sealing length: 60cm.

•Suitable for PP, PE, PVC, NY etc. material bags.

•Timer control

  • Detail
  • Feature
  • Video

Foot type impulse sealer:

• No preheating required.

• Available with PE, PP, PVC, OPP, POF…plastic bag.

 Sealing width could be 2.7mm, 5mm or 10mm

 Additional accessories:

    (1) Can add an electric magnet or pneumatic eqipment for pedal switch controled. labor-saving.

    (2) Date coder.

 For other lengths sealing machine, please contact us.



Item No.

DS-300F

DS-450F

DS-600F

Voltage

100V, 110V, 120V, 220V, 240V

Max. sealing

300x2.7mm or
300x5mm

450x2.7mm or
450x5mm

600x2.7mm or
600x5mm

Machine weight

16 kgs

18kgs

21kgs

Machine size

380x340x880mm

530x340x880mm

680x340x880mm



Item No.

DS-750F

DS-900F

Voltage

100V, 110V, 120V, 220V, 240V

Max. sealing

750x2.7mm or
750x5mm

900x2.7mm or
900x5mm

Machine weight

22kgs

25kgs

Machine size

830x340x880mm

980x340x880mm


Specification
Model No. DS-600F
Sealing type Impulse Heat
Type
Voltage/Ampere  100V,110V,120V,220V,240V
Power
Vacuum capacity
Max.sealing Max:600.0 x 2.7 mm or 600.0 x 5.0 mm
Vacuum time
Sealing time
Cooling time
Machine weight 21.00 kgs
Machine size 680 x 340 x 880 mm
Vacuum flow
Pump capacity
Pump type
Chamber size
Sealing width
Sealing and conveyor speed
Bag total thickness
Bag size
Sealing Temperate
Conveyor width
Conveyor height adjusting range
Conveyor loading weight
Machine size
Packing
Warm up time
Heating
Temperature
Adjusting height of working table
Width of ribbon
Size of letter
Number of letters
Printing area
Size of metal bar
Quantity of knives
Length of knives
Max. consumption electric power
Oscillation frequency
Max. welding
Film position
Size of heating board
Max. size of film
Inner core
Packing size
Working table size
PS2
PS3
Certification
Machine material
Suitable material of bag
Suitable for packing products
Spare parts
Warranty
Origin

60cm Foot type impulse sealer



You May Also Like
Why Choosing Dailysealing
Parts and material quality control
  • Heating elements are from Japan.
  • Motor, Transformers, PCB and vacuum bags are made in Taiwan.
Strict quality control
  • 100% product inspection: The inspection is included functions and appearance of sealing machines.
  • Tensile strength test to ensure the sealing line tensile strength value reaches the customer standard.
  • Electric leakage test: Puncture and insulation test.
  • Our production and inspection are all based on ISO 9001.
Professional packaging and sealing machine factory
  • Produce many kinds sealing machines and ODM/OEM products and provide custom-made services.
  • More than 30 year experiences in packaging machines industry.
  • Sell sealing machines to America, Europe, Latin America and Asia.
  • 85% products in stocks, so we can deliver the products quickly.
  • The production process is based on SOP to ensure the quality of sealing machines consistently.
Complete range of specifications of sealing machines
  • Complete range of specifications of sealing machines.
  • Many kinds of sealing machines and consumptive materials in stocks, so customers can do one-stop shopping here.
  • The customers include Biotechnology companies, Medical equipment companies, Food industry, Electronics industry, Handmade soap industry and other industry..
Custom-made sealing machine service
  • Custom-made sealing machine service
  • Designs of the special sealing machine for irregular shape sealing line, such as U-shape sealing line and L-shape sealing line.
  • Different width of sealing line could be custom-made to meet customer requirements.
After-sales service of professional sealing machine
  • Provide the professional service for repair the broken sealing machine immediately.
  • The sufficient supply of parts stock, so don’t worry about the parts replace.
  • Some parts of sealing machine are used in common specifications, so it is easy to get the parts for replace.
Exhibitions and trade shows
News
Q&A How to make the sealing line of the impulse sealer even and beautiful?
2024/7/5
Q&A How to make the sealing line of the impulse sealer even and beautiful?
Q&A How to make the sealing line of the impulse sealer even and beautiful?   Q: Users often want to know why the sealing line is crooked and thin, rather than the flat and complete 2mm or 5mm wide sealing line tested by the manufacturer. A: The key point is cooling time. For impulse sealers, whether hand type or foot-operated type, both the sealing and cooling time are manually controlled. In order to shorten the package time, many users will ignore the cooling time directly. As soon as the heating time is up and the heating light goes off, they release the handle or foot pedal. This will result in uneven sealing lines.   Q: How long does the cooling time need to be? A: It is recommended to refer to the sealing time. If the heating time is longer, the cooling time should be increased accordingly, but not necessarily in a proportional manner. It still needs to be tested. Based on the experience, if using regular bags and the sealing time is not set for a long time, it is recommended that customers press for an additional 1 second after the heating light goes off (the editor usually counts to 3 in their mind) before releasing the handle or foot pedal.   Q: If I don't care about the appearance of the sealing line, can I ignore the cooling time? A: It is still recommended to have some cooling time. A complete sealing line is not only visually appealing to customers, but the most important, it ensures the bag is securely sealed. The impulse sealer uses heat to stick the bag mouth and seal it tightly, and then cools the sealing line by pressing the bag. This is how the sealing line can be both firm and smooth. Without cooling time to cool the sealing line, the sealing line of the bag mouth may be thin and easily melt and break, which could lead to bag rupture and increase the workload instead.
MORE
How Do You Operate a Vacuum Sealer?
2024/11/15
How Do You Operate a Vacuum Sealer?
How Do You Operate a Vacuum Sealer?   In this article, we delve into the "operation methods of a vacuum sealer," providing you with a clear and understandable guide. Whether you are a newcomer to vacuum sealers or a professional seeking to improve operational efficiency, the following steps will help you better understand how to operate a vacuum sealer.   How Do You Operate a Vacuum Sealer? 1: Preparation 1. Check the Vacuum Sealer: Before starting, ensure the vacuum machine is intact and all power connections are secure. 2. Preheat the Vacuum Machine: Preheat the vacuum sealer to the appropriate temperature according to the manufacturer's instruction manual.   How Do You Operate a Vacuum Sealer? 2: Placing the Vacuum Bag 1. Open the Lid: Gently open the lid of the vacuum sealer. 2. Insert the Sealing Bag: Place the item you need to package into a specialized vacuum sealing bag, ensuring the bag's mouth is smooth and there is enough space to place it in the sealing slot.   How Do You Operate a Vacuum Sealer? 3: Vacuum Sealing 1. Start Vacuum Sealing: Close the lid, select the appropriate vacuum sealing mode, and start the machine to begin the vacuuming process. 2. Sealing: After completing the vacuuming, the machine will automatically seal the bag to ensure it is completely sealed inside.   How Do You Operate a Vacuum Sealer? 4: Finalizing the Seal 1. Check the Seal: After vacuum sealing and sealing, open the lid and take out the sealed bag. Check if the seal is strong to ensure there are no leaks. 2. Further Processing: Store the sealed item as needed or proceed with further packaging.    How Do You Operate a Vacuum Sealer?  Tips: - Maintain Cleanliness: Ensure the vacuum sealer is clean before and after use to prevent food residue or other substances from affecting the seal quality. - Regular Inspection: Regularly check for wear and tear on the vacuum machine, especially the sealing bar, to ensure the best sealing results.   By following the above "operation methods of a vacuum sealer," you can easily complete the sealing process. Whether it's for home use or commercial production, this ensures the freshness and extended shelf life of food, or allows you to reduce the volume and lower the air content of the items you vacuum seal.   Conclusion Mastering the correct "operation methods of a vacuum sealer" can not only improve work efficiency but also ensure packaging quality and extend the preservation time of food. How Do You Operate a Vacuum Sealer?
MORE
Hand Type Sealer
2022/12/15
Hand Type Sealer
Hand type sealer is the easiest sealer for users. Hand type sealer is small size that can save space. Portable sealer is suitable for large and heavy package.   ※ Hand type sealer : ➤For different operating type : - Hand type sealer: table type. Save space. Press the hand lever and hand type sealer start to seal. Easy operating. - Hand press sealer: table type. Pull the lever down to start sealing. It can save effort. 25cm sealing line is suitable for tea bags or coffee bag packing. - Portable sealer is suitable for wide working space. Portable sealer is also suitable for large and heavy articles, such us pallet package.   ➤For different material of package bags : - Impulse hand type sealer/ portable sealer: It is suitable for PE, PP, PET material, and aluminum bags and medical bags. - Constant heat hand type sealer / portable sealer: It is suitable for aluminum bags, vacuum bags and medical bags.   More details: Click here
